Description
Brand - DODGE
Item Number - 005091 DODGE - P4B-BZR-407
Category - Sleeve Bearings - Bronze-Bushed Split Journal Bearing
Shaft Size (inch) - 4.4375
Description - P4B-BZR-407
Weight (lbs) - 89
Length Through Bore (A) inch - 9
Overall Length (B) inch - 16.5
C (inch) - 6.25
Bolt to Bolt Minimum Distance (D min) inch - 13
Bolt to Bolt Maximum Distance (D max) inch - 14
E (inch) - 3.5
F-Bolt Diameter (inch) - 0.875
G (inch) - 1.5
H (inch) - 1.75
Overall Height (J) inch - 7.46875
Base to Center Height (M) inch - 4.125
Grease Cups (Pipe Tap) inch - 0.5
Grease Cups (Number Required) - 1
Grease Cups (Size) - 4
Notes :
P2B - Pillow Block, 2 Bolt Base
BZR - Bronze Bushed Rigid
407 - First Digit: Number Of Inches
Second And Third Digit: Sixteenths Of An Inch
** Images are for representation purposes only
