Description
Brand - DODGE
Item Number - 125728 DODGE - F4B-SXV-55M
Category - Eccentric SXV Collar Ball Bearings (SXV Intermediate Duty 4-Bolt Flange Bearings)
Series - 211
Shaft Size (mm) - 55
Description - F4B-SXV-55M
Weight (kg) - 4.3
Length Through Bore (A) mm - 48.3
Overall Length (B) mm - 165.1
Thickness (C) mm - 59.9
Bolt Center to Center Length (D) mm - 130.2
F-Bolt Diameter - M16
H (mm) - 17.5
J (mm) - 19.6
L (mm) - 76.2
N (mm) - 82.6
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
F4B - 4 bolt flange
SXV - Narrow inner ring, intermediate duty, eccentric locking collar
M - Metric
** Images are for representation purposes only
