Description
Brand - DODGE
Item Number - 125871 DODGE - FC-SC-60M
Category - Setscrew Ball Bearings (SC Normal Duty Piloted Flange Bearings)
Series - 212
Shaft Size (mm) - 60
Description - FC-SC-60M
Weight (kg) - 4.3
Length Through Bore (A) mm - 58.7
Overall Width (B) mm - 181.1
Thickness (C) mm - 64.5
Bolt Circle (D) mm - 152.4
E (mm) - 22.4
F-Bolt Diameter - M12
G (mm) - 42.4
H (mm) - 25.4
K (mm) - 127.00/126.95
L (mm) - 75.4
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
FC - Flanged cartridge
SC - Wide inner ring, normal duty, 65° setscrew locking
M - Metric
** Images are for representation purposes only
