Description
Brand - DODGE
Item Number - 127863 DODGE - INS-SC-30M-SS
Category - Ultra Kleen Mounted Bearings (SC Normal Duty Bearing Stainless Steel Inserts for Ultra Kleen Bearings)
Series - 206
Shaft Size (mm) - 30
Description - INS-SC-30M-SS
Weight (kg) - 0.27
Overall Width (A) mm - 38.6
C (mm) - 17.6
Overall Outer Diameter (D) mm - 62
J (mm) - 4.6
L (mm) - 39.9
N (mm) - M8x1.25
W (mm) - 14.7
Y (mm) - 23.9
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
INS - Insert
SC - Wide inner ring, normal duty, 65° setscrew locking
M - Metric
SS - Stainless Steel Insert
** Images are for representation purposes only
