Description
Brand - DODGE
Item Number - 127864 DODGE - INS-SC-35M-SS
Category - Ultra Kleen Mounted Bearings (SC Normal Duty Bearing Stainless Steel Inserts for Ultra Kleen Bearings)
Series - 207
Shaft Size (mm) - 35
Description - INS-SC-35M-SS
Weight (kg) - 0.44
Overall Width (A) mm - 43.4
C (mm) - 19
Overall Outer Diameter (D) mm - 72
J (mm) - 5.1
L (mm) - 46.7
N (mm) - M8x1.25
W (mm) - 17
Y (mm) - 26.4
Dynamic Load Capacity - Available on Request
Static Load Capacity - Available on Request
Maximum Speed - Available on Request
Notes :
INS - Insert
SC - Wide inner ring, normal duty, 65° setscrew locking
M - Metric
SS - Stainless Steel Insert
** Images are for representation purposes only
