132926 DODGE - 12 SSL PLAIN PILLOW BLOCK

Brand - DODGE
Item Number - 132926 DODGE - 12 SSL PLAIN PILLOW BLOCK
Category - Plain Sleeveoil Pillow Block (R Series)
Description - 12 SSL PLAIN PILLOW BLOCK
Shaft Size (inch) - 12
Weight (lbs) - 1785
STL Item Number - 132768 DODGE - 12 STL PLAIN EXP PILLOW BLOCK
Weight of SSL (lbs) - 2000
Split Thrust Collar Item Number * - 133961 DODGE - 12 PLAIN SLV SPLIT THRUST COLLAR
Weight of Split Thrust Collar (lbs) - 68
Auxiliary Seal Kits Item Number ** - 132819 DODGE - 12 SLV AUX SEAL KIT
Weight of Auxiliary Seal Kit (lbs) - 40
Housing End Cap Kits Item Number - 132566 DODGE - 12 SLV HOUSING END CAP KIT
Weight of Housing End Cap Kit (lbs) - 25
Heater / Thermostat Item Number (120 Volt) - 434729 DODGE - 740W - 120V IMMERSION HTR/ T-STAT COMBO
Weight of Heater / Tharmostat (lbs) - 4
Circulating Oil Inlet Kits Item Number *** - 430155 DODGE - 5712 CO INLET ADAPTOR KIT
Weight of Circulating Oil Inlet Kit (lbs) - 2
Neoprene End Closures Item Number ** - 133997 DODGE - 12 SLV NEOPRENE END CLOSURE
Weight of Neoprene End Closure (lbs) - 1.9
Replacement Liner Assemblies Item Number - 133392 DODGE - 12 PLAIN LINER ASSEMBLY
Weight of Replacement Liner Assemblies (lbs) - 650
A (inch) - 23.25
Overall Length (B) inch - 40
C (inch) - 17
Bolt to Bolt Minimum Distance (D min) inch - 31.25
Bolt to Bolt Maximum Distance (D max) inch - 34.75
E (inch) - 9
F-Bolt Diameter (inch) - 2
G (inch) - 4
H (inch) - 6.75
Overall Height (J) inch - 29.3125
K (inch) - 28.25
L (inch) - 18
Base to Center Height (M) inch - 13.5
N1 (inch) - 7.75
P (inch) - 23.75
S (inch) - 3.5
T (inch) - 7
U (inch) - 5.1875
U2 (inch) - 1.5
V (inch) - 7
V1 (inch) - 2
W (inch) - 11
Z (inch) - 7

Notes :
SSL - Short Series Loaded

* 2 Collars Required To Make A Non-Expansion STL Pillow Blocks
** One required per pillow block end
*** One required per pillow block

**** Images are for representation purposes only
