Description
Brand - FAG
Item Number - 231SM110-MA FAG
Category - Split Spherical Roller Bearing
Weight (m) kg - 9.51
Inner Diameter (d) mm - 110
Outer Diameter (D) mm - 200
Outer Ring Width (C) mm - 62
Inner Ring Width (B) mm - 102
Minimum Chamfer Dimension (r) mm - 2
Basic Radial Dynamic Load Rating (Cr) kN - 390
Basic Radial Static Load Rating (C0r) kN - 570
Limiting Value of Fa/Fr for The Applicability of Diff. Values of Factors X and Y (e) - 0.28
Dynamic Axial Load Factor (Y1) - 2.41
Dynamic Axial Load Factor (Y2) - 3.59
Static Axial Load Factor (Y0) - 2.35
Fatigue Radial Load Limit (Cur) kN - 39
