Description
Brand - FAG
Item Number - B71984-C-T-P4S FAG
Category - Spindle Bearing
Weight (Kg) - 36.8
Inner Diameter (d) mm - 420
Outer Diameter (D) mm - 560
Inner Width (B) mm - 65
Minimum Chamfer Dimension (r) mm - 4
Minimum Chamfer Dimension (r1) mm - 1.5
Distance Between The Apexes Of The Pressure Cones (a) mm - 98
Diameter Shaft Shoulder Clearance (da) mm - 444
Shoulder Diameter Outer Ring Clearance (Da) mm - 536
Maximum Recess Radius (ra) mm - 1.5
Maximum Recess Radius (ra1) mm - 1
Basic Dynamic Load Rating (Cr) kN - 510
Basic Static Load Rating (C0r) kN - 980
Fatigue Limit Load Current (Cur) kN - 32.5
Limiting Speed For Grease Lubrication (nG) rpm - 1700
