Description
Brand - FAG
Item Number - F-570970 FAG
Category - Axial Deep Groove Ball Bearing
Inner Diameter (d) mm - 1700
Outer Diameter (D) mm - 1960
Height (T) mm - 170
Minimum Mounting Dimension (D1) mm - 1700
Dimension (d1) mm - 1960
Chamfer Dimension (r) mm - 7.5
Minimum Mounting Dimension (da) mm - 1828
Maximum Mounting Dimension (Da) mm - 1731
Mounting Dimension (ra) mm - 7.5
Basic Dynamic Load Rating (C) kN - 2400
Basic Static Load Rating (C0) kN - 30000
Limiting Speed for Oil Lubrication (nG oil) 1/min - 170
Axial Run-Out (µm) - 5
Minimum Load Factor (A) - 4860
** Images are for representation purposes only
