Description
Brand - SKF
Item Number - N 1021 KTN9/SP SKF
Category - Cylindrical Roller Bearings Single Row
Bore Diameter (d) mm - 105
Outside Diameter (D) mm - 160
Width (B) mm - 26
Basic Dynamic Load Rating (C) kN - 110
Basic Static Load Rating (C0) kN - 153
Fatigue Load Limit (Pu) kN - 18
Attainable Speeds Grease Lubrication (r/min) - 6300
Attainable Speeds Oil-Air Lubrication (r/min) - 7000
Weight (kg) - 1.65
Shoulder Diameter Inner Ring (d1) mm - 125.2
Raceway Diameter Outer Ring (E) mm - 146
Minimum Chamfer Dimension (r1, r2) mm - 2
Minimum Chamfer Dimension (r3, r4) mm - 1.1
Permissible Axial Displacement From The Normal Position Of One Bearing Ring Relative To The Other (s) mm - 3
Minimum Abutment Diameter Shaft (da) mm - 114
Minimum Abutment Diameter Housing (Da) mm - 148
Maximum Abutment Diameter Housing (Da) mm - 151
Maximum Radius of Fillet (ra) mm - 2
Position of Oil Nozzle (dn) mm - 144.1
Reference Grease Quantity (Gref) mm - 18
** Image is for representation purposes only
