Description
Brand - NADELLA
Item Number - NTA72-21.5T-550 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 150 mm
Length (L) - 550 mm
Extension (E) - 330 mm
Load Capacity for Pair of Rails (Cy) - 3050 N
Load Capacity for Pair of Rails (Cz) - 1525 N
Net Weight - 4.5 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
