Description
Brand - NADELLA
Item Number - NTA72-21.5T-750 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 250 mm
Length (L) - 750 mm
Extension (E) - 450 mm
Load Capacity for Pair of Rails (Cy) - 1250 N
Load Capacity for Pair of Rails (Cz) - 625 N
Net Weight - 6 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA72-21.5T-750 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 250 mm
Length (L) - 750 mm
Extension (E) - 450 mm
Load Capacity for Pair of Rails (Cy) - 1250 N
Load Capacity for Pair of Rails (Cz) - 625 N
Net Weight - 6 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
