Description
Brand - NTN
Item Number - 6820LLB/5K NTN
Also known as - 61820-2RS1 6820LLB
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 100
Outer (D) MM - 115
Width (B) MM - 13
Inner (d) Inch - 3.937
Outer (D) Inch - 4.5276
Width (B) Inch - 0.5118
Weight (kg) - 0.31
Bore - C - Cylindrical Bore
Seal - 2RU - Two Seals / Non Contact Type
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Higher and Lower Temperature Grease
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
