Description
Brand - NTN
Item Number - 7MC3-6322L1BC4 NTN
Also known as - 6322M C4 6322M.C4 6322M/C4 6322M/C4VL0241 6322-M-C4 6322-M-J20AA-C4
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 110
Outer (D) MM - 240
Width (B) MM - 50
Inner (d) Inch - 4.3307
Outer (D) Inch - 9.4488
Width (B) Inch - 1.9685
Weight (kg) - 11.5
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - M - Brass Cage
External Modification - No External Modification
Radial Internal Play - C4 Internal Play (Higher than C3)
Precision - Breakdown Voltage 1000v
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
