Description
Brand - NADELLA
Item Number - NTS28-26H-610-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 610 mm
Extension (E) - 639 mm
Load Capacity for Pair of Rails (Cy) - 1710 N
Load Capacity for Pair of Rails (Cz) - 775 N
Dynamic Load for Lifetime calculation (Cdyn) - 3975 N
Weight - 2.34 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
