Description
Brand - NADELLA
Item Number - NTS43-44H-370-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 370 mm
Extension (E) - 402 mm
Load Capacity for Pair of Rails (Cy) - 1619 N
Load Capacity for Pair of Rails (Cz) - 956 N
Dynamic Load for Lifetime calculation (Cdyn) - 5716 N
Weight - 3.52 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
