Description
Brand - NADELLA
Item Number - NTSF28H-60-210 NADELLA
Category - Telescopic Rails Hardened Linear Guide Partial Extension
Principal Dimensions & Load Ratings (Metric):
Slider Length - 60 mm
Rail Length (L) - 210 mm
Dimension (a) - 10 mm
Dimension (b) - 20 mm
Stroke Length - 110 mm
Slider Weight - 0.0486 kg
Guide Weight - 0.2205 kg
Cage Weight - 0.046 kg
NTSF Weight - 0.3151 kg
Load Capacity for Pair of Rails (Cy) - 4817 N
Load Capacity for Pair of Rails (Cz) - 3373 N
Torque Capacity for Single Rail (Mx) - 15 Nm
Torque Capacities for Pair of Rails (My) - 32 Nm
Torque Capacities for Pair of Rails (Mz) - 48 Nm
Dynamic Load for Lifetime Calculation (C100) - 8947 N
Description of Prefix:
NTSF - Linear guides rails, with one or more sliders running inside a fixed length
♦♦ Images are for representation purposes only
Item Number - NTSF28H-60-210 NADELLA
Category - Telescopic Rails Hardened Linear Guide Partial Extension
Principal Dimensions & Load Ratings (Metric):
Slider Length - 60 mm
Rail Length (L) - 210 mm
Dimension (a) - 10 mm
Dimension (b) - 20 mm
Stroke Length - 110 mm
Slider Weight - 0.0486 kg
Guide Weight - 0.2205 kg
Cage Weight - 0.046 kg
NTSF Weight - 0.3151 kg
Load Capacity for Pair of Rails (Cy) - 4817 N
Load Capacity for Pair of Rails (Cz) - 3373 N
Torque Capacity for Single Rail (Mx) - 15 Nm
Torque Capacities for Pair of Rails (My) - 32 Nm
Torque Capacities for Pair of Rails (Mz) - 48 Nm
Dynamic Load for Lifetime Calculation (C100) - 8947 N
Description of Prefix:
NTSF - Linear guides rails, with one or more sliders running inside a fixed length
♦♦ Images are for representation purposes only
