Description
Brand - NADELLA
Item Number - NTSF63H-530-1970 NADELLA
Category - Telescopic Rails Hardened Linear Guide Partial Extension
Principal Dimensions & Load Ratings (Metric):
Slider Length - 530 mm
Rail Length (L) - 1970 mm
Stroke Length - 1360 mm
Slider Weight - 1.537 kg
Guide Weight - 11.9382 kg
Cage Weight - 1.694 kg
NTSF Weight - 15.1692 kg
Load Capacity for Pair of Rails (Cy) - 150790 N
Load Capacity for Pair of Rails (Cz) - 105586 N
Torque Capacity for Single Rail (Mx) - 992 Nm
Torque Capacities for Pair of Rails (My) - 4750 Nm
Torque Capacities for Pair of Rails (Mz) - 6786 Nm
Dynamic Load for Lifetime Calculation (C100) - 91573 N
Description of Prefix:
NTSF - Linear guides rails, with one or more sliders running inside a fixed length
♦♦ Images are for representation purposes only
Item Number - NTSF63H-530-1970 NADELLA
Category - Telescopic Rails Hardened Linear Guide Partial Extension
Principal Dimensions & Load Ratings (Metric):
Slider Length - 530 mm
Rail Length (L) - 1970 mm
Stroke Length - 1360 mm
Slider Weight - 1.537 kg
Guide Weight - 11.9382 kg
Cage Weight - 1.694 kg
NTSF Weight - 15.1692 kg
Load Capacity for Pair of Rails (Cy) - 150790 N
Load Capacity for Pair of Rails (Cz) - 105586 N
Torque Capacity for Single Rail (Mx) - 992 Nm
Torque Capacities for Pair of Rails (My) - 4750 Nm
Torque Capacities for Pair of Rails (Mz) - 6786 Nm
Dynamic Load for Lifetime Calculation (C100) - 91573 N
Description of Prefix:
NTSF - Linear guides rails, with one or more sliders running inside a fixed length
♦♦ Images are for representation purposes only
