Description
Brand - NADELLA
Item Number - NTV48-20T-450 NADELLA
Category - Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 250 mm
Length (L) - 450 mm
Extension (E) - 450 mm
Load Capacity for Pair of Rails (Cy) - 1250 N
Load Capacity for Pair of Rails (Cz) - 625 N
Net Weight - 1.9 kg
Material - Zinc-plated Steel
Description of Suffixes and Prefixes:
NTV - Telescopic rails full extension
T - Sheetrail
♦♦ Images are for representation purposes only
Item Number - NTV48-20T-450 NADELLA
Category - Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 250 mm
Length (L) - 450 mm
Extension (E) - 450 mm
Load Capacity for Pair of Rails (Cy) - 1250 N
Load Capacity for Pair of Rails (Cz) - 625 N
Net Weight - 1.9 kg
Material - Zinc-plated Steel
Description of Suffixes and Prefixes:
NTV - Telescopic rails full extension
T - Sheetrail
♦♦ Images are for representation purposes only
