Description
Brand - FAG
Item Number - S2BC-404-FL FAG
Category - Split Cylindrical Roller Bearing Housing
Shaft Diameter (d) inch - 4.25
Cartridge Assembly Float Bearing - S2BC-404-FL
Cartridge Assembly Held Bearing - S2BC-404-HD
Length Through Bore (G) inch - 6.375
Outside Diameter Cartridge (L) inch - 10.5
Grease Capacity (lbs) - 2
Cartridge - S2C-408
Weight (kg) - 35.0173024
Bearing Float - S2B-404-FL
Bearing Held - S2B-404-HD
Bearing Weight (kg) - 17.6447288
Basic Dynamic Radial Load Rating (Cr) lbs - 91451
Basic Static Radial Load Rating (C0r) lbs - 131199
Basic Dynamic Axial Load Rating (Ca) lbs - 857
Maximum Limiting Speed (rpm) - 1980
Outside Diameter Bearing (Do) inch - 9
Width Inner Ring (Co) inch - 3.938
Width Outer Ring (Bo) inch - 2.25
Housing Group - 408 Grp
