Description
Brand - INA
Item Number - SL024836-A INA
Also known as - 0001684670000 NNCL4836V
EAN - 4012802460964
Inner (d) MM - 180
Outer (D) MM - 250
Width (B) MM - 69
Inner (d) Inch - 7.0866
Outer (D) Inch - 9.8425
Width (B) Inch - 2.7165
Weight (kg) - 4.1
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
