Description
Brand - INA
Item Number - SL024840-A-C3 INA
Also known as - 0001686290030 NNCL4840V/C3
EAN - 4054365554995
Inner (d) MM - 200
Outer (D) MM - 250
Width (B) MM - 50
Inner (d) Inch - 7.874
Outer (D) Inch - 9.8425
Width (B) Inch - 1.9685
Weight (kg) - 5.9
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
