Description
Brand - INA
Item Number - SL04150-D-PP-2NR INA
Also known as - 858719310000
EAN - 4054364855499
Inner (d) MM - 150
Outer (D) MM - 210
Width (B) MM - 80
Inner (d) Inch - 5.9055
Outer (D) Inch - 8.2677
Width (B) Inch - 3.1496
Weight (kg) - 8.4
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - 2R - 2 Snap Rings in O.D.
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
