Description
Brand - INA
Item Number - SL04160-D-PP-2NR-RR-C3-GA22 INA
Category - Cylindrical Roller Bearing Double Row
Inner (d) MM - 160
Outer (D) MM - 220
Width (B) MM - 80
Inner (d) Inch - 6.2992
Outer (D) Inch - 8.6614
Width (B) Inch - 3.1496
Weight (kg) - 8.324
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - 2R - 2 Snap Rings in O.D.
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Grease -50°C / +120°C
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
